DSE4620 | Auto Mains Failure Control Module
- DC SUPPLY
CONTINUOUS VOLTAGE RATING: 8 V to 35 V Continuous - VOLTAGE RANGE: 15 V to 415 V AC (Ph-N) / 26 V to 719 V AC (Ph – Ph)
- FREQUENCY RANGE: 3.5 Hz to 75 Hz
- GENERATOR
- VOLTAGE RANGE: 15 V to 415 V AC (Ph-N) / 26 V to 719 V (Ph – Ph)
- FREQUENCY RANGE: 3.5 Hz to 75 Hz
- MAGNETIC PICK-UPVOLTAGE RANGE: +/- 0.5 V to 70 V
- FREQUENCY RANGE: 10,000 Hz (max)
- Large back-lit icon LCD display.
- 3-phase generator sensing.
- 600 V ph-ph nominal system compatibility.
-
Generator & load power monitoring (kW, kV A, kV Ar, pf).
- Engine speed protection, engine hours counter, engine pre-heat, engine run-time scheduler, engine idle control for start/stop.
Call for Quote for international purchases!
$565.99
SKU: 4620-03
Categories: Auto Mains Failure
DSE4620 Compact Auto Mains (Utility) Failure Control Module (MPU,CT,RTC) - Developed to provide an outstanding range of features within a compact enclosure - Free shipping.
OVERALL SIZE
140 mm x 113 mm x 43 mm (5.5” x 4.4” x 1.5”)
PANEL CUTOUT SIZE
118 mm x 92 mm (4.6" x 3.6")
MAXIMUM PANEL THICKNESS
8.0 mm (0.3”)
WEIGHT
0.28kg
PRODUCT VARIANTS
4620-03 - 4620 Auto Mains (Utility) Failure Control Module (Mpu,Ct,Rtc)
DSE4620
(pdf, 1340KB)
