Original DSE3110 | Manual & Auto Start Control Module

Standard engine and electronic CAN bus variants.
Configurable inputs/outputs (6 digital inputs/4 outputs – 2 outputs configurable on magnetic pick-up variant).
Remote start input.
Comprehensive display parameters.
Engine pre-heat.
Configurable timers & alarms.
Large back-lit icon LCD display.
DSE Configuration Suite PC Software.
Instant integration with both standard and modern electronically controlled engines.
Provides multiple installation options.
Provides a simple connection to operate the generator from a remote location.

Call for Quote for international purchases!

$295.99

Compare

SKU: DSE3110

Categories: Manual & Auto Start

Tags:Control Modules, DSE, DSE 3110, DSE3110, DSEGenset

Description

The DSE3110 can be utilised as a manual or auto start module for single gen-set applications or engine only applications. The module has been designed to work with non-electronic engines, providing advanced engine monitoring and protection features.

The DSE3110 includes a back-lit icon LCD display which clearly shows the status of the generator set at all times. The module monitors engine speed, frequency, voltage and engine run hours and also displays the warning and shutdown status.

The module includes fixed and configurable outputs as well as configurable inputs making this product ideal for a wide variety of applications. The module can either be programmed using the front panel or by using the DSE Configuration Suite PC software.

OVERALL SIZE
98 mm x 79 mm x 40 mm (3.9” x 3.1” x 1.6”)
PANEL CUTOUT SIZE
80 mm x 68 mm (3.1 " x 2.7")
MAXIMUM PANEL THICKNESS
8.0 mm (0.3”)
WEIGHT
0.16kg
PRODUCT VARIANTS
3110-01 - Manual & Auto Start Control Module (Mpu)
3110-02 - Manual & Auto Start Control Module (Can)
3110-31 – Manual & Auto Start Control Module (Mpu) UL CC
