Original DSE7310 MKII | Auto Start Control Module
- Advanced PLC functionality including multi-purpose PIDs
- Flexible inputs and outputs
- DSENet® Expansion Support
- PC configuration using DSE Configuration Suite
- Multiple language support
- Enhanced 4-line text display
- Integrated RS232 and RS485 ports providing Modbus RTU support
- Data logging of up to 10 parameters
- Multi-level pin protected front panel editor
- Manual front panel and automatic control modes
- Latest ECU / ECM support for a wide range of engine manufacturers
- Multiple selectable configurations
- IP65 rating (with supplied gasket) offers increased resistance to water ingress
- 3 phase generator sensing with protection
- Manual starting / control by fascia button and automatic starting / control by inputs and other functions
Call for Quote for international purchases!
Price range: $896.99 through $938.29
The DSE7310 MKIIÂ is an auto start control module suitable for a wide variety of single, diesel or gas, gen-set applications. Monitoring an extensive number of engine parameters, the modules will display warnings, shutdown and engine status information on the back-lit LCD screen, illuminated LEDs and remote PC.
The module include USB, RS232 and RS485 ports as well as dedicated DSENet® terminals for system expansion. The DSE7310 MKII is compatible with electronic (CAN) and non-electronic (magnetic pick-up/alternator sensing) engines and offer an extensive number of flexible inputs, outputs and extensive engine protections so the system can be easily adapted to meet the most demanding industry requirements. The extensive list of features includes enhanced event and performance monitoring, remote communications & PLC functionality.
OVERALL SIZE
245 mm x 184 mm x 51 mm (9.6" x 7.2" x 2.0")
PANEL CUTOUT SIZE
220 mm x 160 mm (8.7" x 6.3")
MAXIMUM PANEL THICKNESS
8.0 mm (0.3")
PRODUCT VARIANTS
7310-03 MKII Auto start Control Module
7310-33 MKII Auto Start Controller
7310-34 MKII Auto Start Controller with Heated Display
