DSE855 | USB to Ethernet Communications Device | DSE855-01
- CONTINUOUS VOLTAGE RATING: 8 V to 35 V Continuous
CRANKING DROPOUTS: Able to survive 0 V for 100 mS, providing supply was at least 10 V before dropout and supply recovers to 5 V. This is achieved without the need for internal batteries. LEDs and backlight will not be maintained during cranking. - MAXIMUM OPERATING CURRENT: 123 mA at 12 V 71 mA at 24 V
- MAXIMUM STANDBY CURRENT: 104 mA at 12 V 63 mA at 24 V
- COMMUNICATIONS: USB (Single DSE Controller) Ethernet
- Converts a USB port to an Ethernet port.
- In-built web server.
- Simple Internet browser configuration.
- Remote control & monitoring for all connected modules.
- MODBUS TCP support via Ethernet.
- Can be viewed from four separate locations simultaneously.
- Full building management system integration.
- Firmware upgradeable.
- DIN rail mount.
Call for Quote for international purchases!
$163.01
SKU: 855-01
Categories: Remote Monitoring
The DSE855 communications device allows monitoring of a single DSE controller with USB connectivity over a LAN or WAN connection. To achieve this the DSE855 utilises its in-built web server or MODBUS TCP. In order to use over a LAN connection the on-site router must be configured to be accessible from any global location.
OVERALL SIZE
35 mm x 97 mm x 102 mm (1.4” x 3.8” x 4.0”)
WEIGHT
0.16kg
PRODUCT VARIANTS
0855-01 - 855 USB to Ethernet Communications Device
DSE855
(pdf, 81KB)
